Load Cell Type Soil Pressure Gauge

KDG-PA/KDH-PA Load Cell type Soil Pressure Gauge 200kPa to 2MPaCE

These are all-stainless steel soil pressure gauges each 100 mm in outer diameter. They are load cell-type soil pressure gauges that are less sensitive to side pressure. KDG-PA and KDH-PA models are available with differing cable exit directions.

Protection ratings : IP 68 equivalent

KDG-PA/KDH-PA Load Cell type Soil Pressure Gauge
Features
  • Made of all stainless steel with excellent corrosion resistance
  • Robuster than the diaphragm type
  • Specifications

    Type Capacity Rated output Non-linearity Temperature range
    KDG-200KPA
    KDH-200KPA
    200kPa Approx. 1 mV/V (2000x10-6 strain) 1 %RO -20 to +60 ℃
    KDG-500KPA
    KDH-500KPA
    500kPa
    KDG-1MPA
    KDH-1MPA
    1MPa
    KDG-2MPA
    KDH-2MPA
    2MPa

    Output polarity

    Measurement moves in the plus direction with regard to an increase in pressure.

KDJ-PA/KDK-PA Load Cell type Soil Pressure Gauge 200kPa to 2MPaCE

These are all-stainless steel soil pressure gauges each 200 mm in outer diameter. They are load cell-type soil pressure gauges that are less sensitive to side pressure. KDJ-PA and KDK-PA models are available with differing cable exit directions.

Protection ratings : IP 68 equivalen

KDJ-PA/KDK-PA Load Cell type Soil Pressure Gauge
Features
  • Made of all stainless steel with excellent corrosion resistance
  • Robuster than the diaphragm type
  • Specifications

    Type Capacity Rated output Non-linearity Temperature range
    KDJ-200KPA
    KDK-200KPA
    200kPa Approx. 1 mV/V (2000x10-6 strain) 1 %RO -20 to +60 ℃
    KDJ-500KPA
    KDK-500KPA
    500kPa
    KDJ-1MPA
    KDK-1MPA
    1MPa
    KDJ-2MPA
    KDK-2MPA
    2MPa

    Output polarity

    Measurement moves in the plus direction with regard to an increase in pressure.
