Strain Gauge Adhesives CN-E adhesives(Concrete, Mortar)

CN-E adhesives(Concrete, Mortar)

Single-component adhesive featuring high viscosity for bonding strain gauges to porous materials such as concrete and mortar. Curing time under normal conditions is 40~120 seconds.

CN-E 接着剤（コンクリート・モルタル）

  • Specifications
    TYPE CN-E
    Single component Room-temperature-curing
    Contents Single 2 g x 5
    Component Cyanoacrylate
    Applicable specimen Concrete, Mortar, Wood
    Operating temperature -30 to +120 ℃
    Curing temperature and time Room temperature 40sec. to 2 min.
    (thumb pressure:100 to 300kPa)
    Shelf life 6 months

More Information

Strain Gauge Adhesives CN adhesives(General purpose)

CN adhesives(General purpose)

Single-component adhesive for strain gauges. The time required to bond the gauge is extremely short and handling is very easy. The thin bonding layer allows adhesion to plastic objects as well as metal. Curing time under normal conditions is 20~60 seconds.

CN 接着剤（汎用）

  • Specifications
    TYPE CN
    Single component Room-temperature-curing
    Contents Single 2 g x 5
    Component Cyanoacrylate
    Applicable specimen Metal, Plastics, Composite
    Operating temperature -196 to +120℃
    Curing temperature and time Room temperature 20sec. to 1 min.
    (thumb pressure:100 to 300kPa)
    Shelf life 6 months

More Information

Strain gauge with a connector　Lead wires with connector

Lead wires with connector

Special extension lead wire for connector-integrated strain gauges, standard lengths are 10 m and 20 m. These lead wires can be used repeatedly. In addition to standard lead wire lengths, we can make lead wires to any length (made-to-order).

  • Specifications

    Lead wires with connector (irregular 3-wire, 2-wire system)

    Type (10 m) 10LCJC
    Conductors/wire diameter (cross-sectional area) 10/0.12（0.11mm2)



    Lead wires with connector (3-wire system)

    Type (10 m) 10LCJCT
    Conductors/wire diameter (cross-sectional area) 10/0.12（0.11mm2)
