UBF series Composite strain gauge Composite Strain Gauge

UBF series Composite strain gauge CE

These are strain gauges developed for measurement on composite materials, and are designed with a proprietary special grid pattern to reduce the stiffening effect of the strain gauges. Owing to the development of gauge backing with better compliance, the number of repetitions in thermal cycling tests and creep characteristics have been significantly improved compared to conventional strain gauges (Tokyo Measuring Instruments Laboratory comparison). Optional (-F) lead-free solder specifications are also available.

UBF series Composite strain gauge
Applicable specimen Fiber Reinforced Plastics(FRP)
Operational temperature Static:-30 to +120 Ω
Dynamic:-30 to +150 Ω
Temperature compensation range -
Temperature compensation range EB-2, CN, NP-50B
Backing Polyimide-Amide
Element Cu-Ni
Strain limit 3% (30000 x 10-6 strain)
Fatigue life at room temperature 1×106 (±1500 x 10-6 strain)

  • Single-element
    Gauge pattern Type Gauge
    length
    (mm)    		 Gauge
    width
    (mm)    		 Backing
    length
    (mm)    		 Backing
    width
    (mm)    		 Resistance
    (Ω)
    img_ubf_01 UBFLA-03 0.3 1.9 3.4 2.5 120
    img_ubf_02 UBFLA-1 1 1.3 4.5 2 120

    * Optional -F availability (lead-free solder)
    Each package contains 10 gauges.

  • Lead wires recommended for UBF series strain gauges (made-to-order)
    Purpose Lead wires Lead wire symbol Operating temperature range
    (℃ )    		 Gauge type exampled
    General measurement (no temperature change) 2-wire parallel vinyl wire LJB-F －20 to +80 UBFLA-1-3LJB
    2-strand twisted vinyl wire LH UBFLA-1-3LH
    General measurement 3-wire parallel vinyl wire LJBT/LJBT-F －20 to +80 UBFLA-1-3LJBT
    3-strand twisted vinyl wire (3-wire system) LHT UBFLA-1-3LHT
    Medium/high temperature 3-wire parallel special vinyl wire LXT/LXT-F －20 to +150 UBFLA-1-3LXT
    3-strand twisted FEP single-core wire 6FB♦LT －269 to +200 UBFLA-1-6FB3LT

    * "♦" indicates lead wire length

More Information

High Temperature Use Strain Gauge QF series

QF series strain gauges for high temperature use

These are foil strain gauges having a polyimide resin backing.  Strain measurement in high temperature is easily performed by bonding the strain gauge with room temperature curing adhesive NP-50B.  Strain gauges for stress concentration measurement or torque measurement are also available in addition to general use gauges in this series.
New series of strain gauges named GOBLET are added to this series.  They are compliant with RoHS 2 Directive 2011/65/EU and supplied with CE marking.  Even though lead-free solder is used in the GOBLET gauges, they show better performance than conventional strain gauges owing to the adoption of unique gauge pattern.  Extension leadwires with CE marking are also available.

QF series strain gauges for high temperature use
Applicable specimen Metal, Ceramics
Operational temperature QF GOBLET  : -30 to +200℃
QF : -20 to +200℃
Temperature compensation range +10 to +100℃
Applicable adhesive CN, NP-50B, C-1
Backing Polyimide
Element Cu-Ni alloy foil
Strain limit 3% (30000 x 10-6 strain)
Fatigue life at room temperature 1×106 (±1500 x 10-6 strain)

  • GENERAL USE GOBLET series goblet_log_s Single-element/2-element/3-elementCE

    Single-element (G.F. 2.1 approx.)

    Gauge pattern Type

    Gauge
    length
    (mm)

    Gauge
    width
    (mm)

    Backing
    length
    (mm)

    Backing
    width
    (mm)

    		 Resistance
    (Ω)
    qflgb_0211 QFLGB-02-11 0.2 1.4 3.5 2.5 120
    qflkb_111 QFLKB-1-11 1 0.7 4.5 1.4 120
    QFLKB-2-11 2 0.9 5.5 1.5 120
    qflab_511 QFLAB-03-11 0.3 1.4 3 2 120
    QFLAB-1-11 1 1.1 4.7 2 120
    QFLAB-2-11 2 1.5 6.5 3 120
    QFLAB-3-11 3 1.7 7.7 3.5 120
    QFLAB-5-11 5 1.5 10 3 120
    QFLAB-6-11 6 2.2 11 4.3 120
    QFLAB-30-11 30 2 35 5 120
    QFLAB-1-350-11 1 1.6 4.5 3 350
    QFLAB-1W-350 1 2 4.7 3.6 350
    QFLAB-2-350-11 2 1.9 6 3.5 350
    QFLAB-3-350-11 3 1.6 7.2 3 350
    QFLAB-3W-350 3 3.2 8.5 5 350
    QFLAB-6-350-11 6 2.6 10.8 4.5 350
    QFLAB-6-1000-11 6 4.6 11 7 1000

    Each package contains 10 strain gauges



    2-element 0°/90°(G.F. 2.1 approx.)

    Gauge pattern Type

    Gauge
    length
    (mm)

    Gauge
    width
    (mm)

    		 Backing
    (mm)    		 Resistance
    (Ω)
    qfcab_111 QFCAB-1-11 1 0.7 Φ4.5 120
    QFCAB-3-11 3 1.7 Φ11 120

    Each package contains 10 strain gauges



    3-element 0°/45°/90° (G.F. 2.1 approx.)

    Gauge pattern Type

    Gauge
    length
    (mm)

    Gauge
    width
    (mm)

    		 Backing
    (mm)    		 Resistance
    (Ω)
    qfrab_111 QFRAB-1-11 1 0.7 Φ4.5 120
    QFRAB-3-11 3 1.7 Φ11 120

    Each package contains 10 strain gauges

  • GENERAL USE Single-element/2-element/3-element

    Single-element (G.F. 2.1 approx.)

    Gauge pattern Type

    Gauge
    length
    (mm)

    Gauge
    width
    (mm)

    Backing
    length
    (mm)

    Backing
    width
    (mm)

    		 Resistance
    (Ω)
    qflg_0211 QFLG-02-11 0.2 1.4 3.5 2.5 120
    qfbx_0411005le
    Polyimide 5 cm pre-attached    		 QFBX-04-11-005LE 0.4 1.3 5.4 1 120
    qfby_0611005le
    Polyimide 5 cm pre-attached    		 QFBY-06-11-005LE 0.6 0.8 5.3 1 120
    qflx_111002le
    Polyimide 2 cm pre-attached    		 QFLX-1-11-002LE 1 1.3 5 2 120
    qflk_111 QFLK-1-11 1 0.7 4.5 1.4 120
    QFLK-2-11 2 0.9 5.5 1.5 120
    qfla_511 QFLA-1-11 1 1.1 4.7 2 120
    QFLA-2-11 2 1.5 6.5 3 120
    QFLA-3-11 3 1.7 8.8 3.5 120
    QFLA-5-11 5 1.5 10 3 120
    QFLA-6-11 6 2.2 12.5 4.3 120
    QFLA-1-350-11 1 2 4.7 3.6 350
    QFLA-2-350-11 2 1.9 6.1 3.5 350
    QFLA-3-350-11 3 3.2 8.5 5 350
    QFLA-6-350-11 6 2.6 12.5 4.5 350
    QFLA-6-1000-11 6 4.6 13.7 7 1000

    Each package contains 10 strain gauges



    2-element 0°/90°(G.F. 2.1 approx.)

    Gauge pattern Type

    Gauge
    length
    (mm)

    Gauge
    width
    (mm)

    Backing
    length
    (mm)

    Backing
    width
    (mm)

    		 Resistance
    (Ω)
    qfca_111 QFCA-1-11 1 1.3 7.2 7.2 120
    QFCA-3-11 3 1.7 11 11 120
    qfcb_211 QFCB-2-11 2 1.5 8.2 8 120

    Each package contains 10 strain gauges



    3-element 0°/45°/90° (G.F. 2.1 approx.)

    Gauge pattern Type

    Gauge
    length
    (mm)

    Gauge
    width
    (mm)

    Backing
    length
    (mm)

    Backing
    width
    (mm)

    		 Resistance
    (Ω)
    qfra_111 QFRA-1-11 1 1.3 7.2 7.2 120
    QFRA-3-11 3 1.7 11 11 120

    Each package contains 10 strain gauges

  • STRESS CONCENTRATION MEASUREMENT
    Gauge pattern Type

    Gauge
    length
    (mm)

    Gauge
    width
    (mm)

    Backing
    length
    (mm)

    Backing
    width
    (mm)

    		 Resistance
    (Ω)    		 Gauge leads gauge pitch
    5-element single axis X-axis direction (G.F.2.1 approx.)
    qfxv_111002le    		 QFXV-1-
    11-002LE    		 1 1.3 5 12 120 Polyimide 2 cm pre-attached 2 mm
    qfbxv_0411005le QFBXV-04-
    11-005LE    		 0.4 1.3 5.4 7.4 120 Polyimide 5 cm pre-attached 1 mm
    5-element single axis Y-axis direction (G.F.2.1 approx.)
    qfyv_111002le    		 QFYV-1-
    11-002LE    		 1 1.4 5 12 120 Polyimide 2 cm pre-attached 2 mm
    qfbyv_0611005le QFBYV-06-
    11-005LE    		 0.6 0.8 5.3 7 120 Polyimide 5 cm pre-attached 1 mm

    Each package contains 10 strain gauges.

  • TORQUE MEASUREMENT
    Gauge pattern Type

    Gauge
    length
    (mm)

    Gauge
    width
    (mm)

    Backing
    length
    (mm)

    Backing
    width
    (mm)

    		 Resistance (Ω)
    qfct_211 QFCT-2-11 2 1.5 8.7 6.5 120
    QFCT-2-350-11 2 1.5 7.6 5.3 350

    Each package contains 10 strain gauges.

  • Single axis shearing strain measurement

    Single axis 45° direction(G.F. 2.1 approx.)
    Gauge pattern Type

    Gauge
    length
    (mm)

    Gauge
    width
    (mm)

    Backing
    length
     (mm)

    Backing
    width
     (mm)

    		 Resistance (Ω)
    qflt_1a11002le
    Polyimide 2-wire 2 cm pre-attached    		 QFLT-05A-11-002LE 0.55 0.66 4.0 1.3 120
    QFLT-1A-11-002LE 1.2 1.1 5.7 2 120
    QFLT-1-350A-11-002LE 1.2 1.1 5.7 2 350
    qflt_1b11002le
    Polyimide 2-wire 2 cm pre-attached    		 QFLT-05B-11-002LE 0.55 0.66 4.0 1.3 120
    QFLT-1B-11-002LE 1.2 1.1 5.7 2 120
    QFLT-1-350B-11-002LE 1.2 1.1 5.7 2 350

    Each package contains 10 strain gauges.

  • Recommendable integral leadwire for QF series (Made to order)

    Recommendable integral leadwire for QF series

    Application Product name Lead wire code Operating temperature (℃) Leadwire code exampled
    General measurement (no temperature change) 2-wire parallel vinyl wire LJC/LJC-F -20 to +80 QFLA-1-11-3LJC
    General measurement 3-wire parallel vinyl wire LJCT/LJCT-F -20 to +80 QFLA-1-11-3LJCT
    Waterproof 3-strand twisted cross-linked vinyl wire LJRTA -20 to +100 QFLA-1-11-3LJRTA
    High temperature 3-strand twisted FEP wire 6FA_LT/6FA_LT-F -269 to +200 QFLA-1-11-6FA3LT
    3-strand twisted FEP single-core wire 6FB_LT/6FB_LT-F QFLA-1-11-6FB3LT

    The length of lead wire in meter is filled in _.
    Only the leadwires using lead-free solder are available for GOBLET strain gauges with CE marking.

More Information

Load Cell Type Soil Pressure Gauge KDJ-PA/KDK-PA

KDJ-PA/KDK-PA Load Cell type Soil Pressure Gauge 200kPa to 2MPaCE

These are all-stainless steel soil pressure gauges each 200 mm in outer diameter. They are load cell-type soil pressure gauges that are less sensitive to side pressure. KDJ-PA and KDK-PA models are available with differing cable exit directions.

Protection ratings : IP 68 equivalen

KDJ-PA/KDK-PA Load Cell type Soil Pressure Gauge
Features
  • Made of all stainless steel with excellent corrosion resistance
  • Robuster than the diaphragm type

  • Specifications
    Type Capacity Rated output Non-linearity Temperature range
    KDJ-200KPA
    KDK-200KPA    		 200kPa Approx. 1 mV/V (2000x10-6 strain) 1 %RO -20 to +60 ℃
    KDJ-500KPA
    KDK-500KPA    		 500kPa
    KDJ-1MPA
    KDK-1MPA    		 1MPa
    KDJ-2MPA
    KDK-2MPA    		 2MPa

    Output polarity

    Measurement moves in the plus direction with regard to an increase in pressure.

More Information

Load Cell Type Soil Pressure Gauge KDG-PA/KDH-PA

KDG-PA/KDH-PA Load Cell type Soil Pressure Gauge 200kPa to 2MPaCE

These are all-stainless steel soil pressure gauges each 100 mm in outer diameter. They are load cell-type soil pressure gauges that are less sensitive to side pressure. KDG-PA and KDH-PA models are available with differing cable exit directions.

Protection ratings : IP 68 equivalent

KDG-PA/KDH-PA Load Cell type Soil Pressure Gauge
Features
  • Made of all stainless steel with excellent corrosion resistance
  • Robuster than the diaphragm type

  • Specifications
    Type Capacity Rated output Non-linearity Temperature range
    KDG-200KPA
    KDH-200KPA    		 200kPa Approx. 1 mV/V (2000x10-6 strain) 1 %RO -20 to +60 ℃
    KDG-500KPA
    KDH-500KPA    		 500kPa
    KDG-1MPA
    KDH-1MPA    		 1MPa
    KDG-2MPA
    KDH-2MPA    		 2MPa

    Output polarity

    Measurement moves in the plus direction with regard to an increase in pressure.

More Information

PMFLS series Asphalt Mold strain gauge Mold Strain Gauge

PMFLS series Asphalt Mold strain gaugeCE

These mold strain gauges are embedded in asphalt for use in such applications as loading tests with rolling compaction. Material used in the backing is super engineering plastic featuring water and heat resistance. The gauges can withstand a high temperature of up to 200℃ during placing of asphalt.
Gauges are temperature-compensated for asphalt.

PMFLS series Asphalt Mold strain gauge
Applicable specimen Asphalt
Operational temperature -20 to +60℃
Temperature compensation range -
Bonding adhesive Embedment
Backing Super engineering plastics
Element Cu-Ni alloy
Strain limit -
Fatigue life at room temperature -
