Measurement Box

Measurement Box T-ZACCS BOX EX-50H

This is a measurement box dedicated to T-ZACCS9 TS-960. The number of measuring point is 50, and various inputs such as strain gauges, strain gauge type transducers, thermocouples, Pt-RTDs and dc voltage can be measured. Owing to the introduction of our unique next-generation A/D conversion method that enables high-speed measurement with high accuracy and stability, and also of ultra high-speed field network that is based on Ethernet, highly accurate and stable measurement is enabled eliminating the influence of various thermoelectromotive forces, thermal zero shift of amplifier, and power line noise. Measurement is possible at intervals of 0.1 seconds in high-speed mode and 0.4 seconds in high-accuracy mode (in 50Hz area) regardless of the number of measuring point.

ex-50h
Features
  • Measures 1000 points in 0.1 seconds at the fastest by the adoption of ultra high-speed field network
  • Highly accurate and stable measurement achieved by the adoption of our unique next-generation A/D conversion method that enables high-speed measurement with high accuracy and stability eliminating the influence of various thermoelectromotive forces, thermal zero shift of amplifier, and power line noise
  • In high-accuracy mode, measures 1000 points in 0.4 seconds (in 50Hz area) even for thermocouple measurement and/or using high-resolution mode
  • A temperature-integrated strain gauge can be measured using one channel
  • Complete compensation method of strain (Comet) provided
  • Various check functions (insulation check, sensitivity check, dispersion check, thermocouple burnout check)
  • Specifications

    Type EX-50H
    Measurement object Strain gauge, Strain gauge type transducer
    DC voltage, Thermocouple, Pt-RTD
    Number of measuring point 50 points
    Measuring speed High-speed mode 0.1 seconds
    High-accuracy mode 0.4 seconds(50Hz) / 0.34 seconds(60Hz)
    Number of connection 20 boxes at maximum
    Extension distance 100 m (between instruments)
    Connection cable EX connection cable (CR-89**)
    External dimensions 320 (W) × 130 (H) × 490 (D) mm
    Weight Approx. 10 kg
    Power supply AC 100 ~ 240 V   50/60 Hz  104 VA Max.

Measurement Unit T-ZACCS UNIT EU-10H

This is a measurement box dedicated to T-ZACCS9 TS-963/-960. The number of measuring point is 10, and various inputs such as strain gauges, strain gauge type transducers, thermocouples, Pt-RTDs and dc voltage can be measured. Owing to the introduction of our unique next-generation A/D conversion method that enables high-speed measurement with high accuracy and stability, and also of ultra high-speed field network that is based on Ethernet, highly accurate and stable measurement is enabled eliminating the influence of various thermoelectromotive forces, thermal zero shift of amplifier, and power line noise. Measurement is possible at intervals of 0.1 seconds in high-speed mode and 0.4 seconds in high-accuracy mode (in 50Hz area) regardless of the number of measuring point.

測定ユニット
Features
  • Measures 1000 points in 0.1 seconds at the fastest by the adoption of ultra high-speed field network
  • Highly accurate and stable measurement achieved by the adoption of our unique next-generation A/D conversion method that enables high-speed measurement with high accuracy and stability eliminating the influence of various thermoelectromotive forces, thermal zero shift of amplifier, and power line noise
  • In high-accuracy mode, measures 1000 points in 0.4 seconds (in 50Hz area) even for thermocouple measurement and/or using high-resolution mode
  • A temperature-integrated strain gauge can be measured using one channel
  • Complete compensation method of strain (Comet) provided
  • Various check functions (insulation check, sensitivity check, dispersion check, thermocouple burnout check)
  • Specifications

    Type EU-10H
    Measurement object Strain gauge, Strain gauge type transducer
    DC voltage, Thermocouple, Pt-RTD
    Number of measuring point 10 points
    Measuring speed High-speed mode 0.1 seconds
    High-accuracy mode 0.4 seconds(50Hz) / 0.34 seconds(60Hz)
    Number of connection 100 boxes at maximum (including the TS-960 built-in)
    Extension distance 100 m (between instruments)
    Connection cable EX connection cable (CR-89**)
    External dimensions 320 (W) × 98(H) × 183 (D) mm
    Weight Approx. 3 kg
    Power supply AC 100 ~ 240 V   50/60 Hz  86 VA Max.

Digital Displacement Sensor Measurement Unit T-ZACCS UNIT EU-10D

This is a 10-channel measuring unit exclusively for TS-960/TS-963.
It can measure digital displacement sensors with 10 measurement points.Can be used with T-ZACCS BOX EX-10H, T-ZACCS UNIT EU-10H, and EU-10VO at the same time.

EU-10D
Features
  • Combined with T-ZACCS9 TS-963/-960, digital displacement sensor measurement is available
  • Compatible with two types of digital displacement sensors
  • No signal degradation because it is handled as a digital signal
  • Can be used with T-ZACCS BOX EX-50H, T-ZACCS UNIT EU-10H, and EU-10VO at the same time
  • 仕様

    型名 EU-10D
    測定点数 10 点
    対応デジタル
    変位センサ
      Sensor A(5V) Sensor B(12V)
    適合コネクタ R03-PB6M(多治見製) R03-PB8M(多治見製)
    センサ供給電源 4.5~5.5V(100mA) 11.4~12.6V(50mA)
    ピンアサイン A : A 相
    B : B 相
    C : +5V
    D : NC
    E : GND
    F : GND
    A : GND
    B : A 相
    C : +12V
    D : B 相
    E : NC
    F : シールド
    G : NC
    H : NC
    入力信号 矩形波電圧入力
    カウント形式 A 相+B 相の位相差によるアップダウンカウント
    測定範囲 ±640000 積算カウント
    測定速度 0.1 秒
    測定精度 使用するデジタル変位センサによる
    測定分解能 使用するデジタル変位センサによる
    量子化誤差 ±1 カウント
    カウントリセット 電源ON 時/フルカウント
    接続台数 最大100ユニット接続(TS-960内蔵分含む)
    延長距離 100m(機器間)
    接続ケーブル EX 用接続ケーブル(CR-89**)
    外形寸法 328(W)×183(D)×98(H)mm
    質量 約3kg
    電源 AC100~240V 50/60Hz 86VA MAX

Switching Box Protocol Converter T-ZACCS + EI-01P

Switching box protocol converter for T-ZACCS9 TS-963/-960. The ISW-50G/IHW-50G switching boxes can be connected to the T-ZACCS9 TS-963/-960 for operation. One switching box can be operated with one unit of this converter.

EI-01P
Features
  • T-ZACCS9 TS-963/-960 enables measurement of switching box ISW-50G/IHW-50G
  • Easy handling with no special settings required
  • Corresponding to 1-gauge 4-wire measuring method
  • Specifications

    Type EI-01P
    Function Connection with switching box ISW-50G/IHW-50G
    *Measurement speed and sensor mode depend on switching box
    Connection with data logger
    Number of connectable units Up to 20 units (in total including EX-50H)
    Extension distance 100m (between devices)
    Connection cable Connection cable for EX (CR-89**)
    Connection with switching box
    Target model IHW-50G, ISW-50G
    ELECTRICAL (RS-422) Number of connectable units 1 unit, 50 points
    Extension distance 2m
    Connection cable Extension cable for ISW/IHW(CR-832M)
    External dimensions 160(W)×60(H)×171.5(D)mm
    Weight Approx. 1 kg
    Power supply AC100 to 240V 50/60Hz 12VA MAX
