Acceleration Transducer mounting plate

There are five types of mounting plate to suit the following acceleration teansducers. Six pieces of fixing bolt M2x5mm are supplied.

Type  Applicable Acceleration Transducer
img-arjf-11-01ARJF-11

ARJ-A Side or Bottom mounting
ARJ-A-D Side or Bottom mounting
ARJ-A-T Side mounting
ARJ-A-T Side or bottom mounting
ARK-A Side or Bottom mounting

img-arjf-12-01ARJF-12 ARJ-A-T Bottom mounting
img-arff-11-01ARFF-11 ARF-A Side mounting
ARFF-12ARFF-12 ARF-A Tri-axial mounting
img-arhf-11-01ARHF-11 ARH-A Side mounting
img-arsf-11-01ARSF-11 ARS-A Side mounting
